IFM Sensor DI601A

Product characteristics
Electrical design PNP
Output function normally open / normally closed; (parameterisable)
Sensing range [mm] 12
Dimensions [mm] M18 x 1 / L = 68
Application
Special feature Gold-plated contacts
Application evaluation of rotating and linear movements with regard to underspeed; blocking
Electrical data
Nominal voltage DC [V] 10...36
Current consumption [mA] < 15
Protection class II
Reverse polarity protection yes
Outputs
Electrical design PNP
Output function normally open / normally closed; (parameterisable)
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 150; (when used outside the hazardous area: 250; Pulse output: 15)
Short-circuit protection yes
Type of short-circuit protection pulsed
Overload protection yes
Detection zone
Sensing range [mm] 12
Sensing range adjustable no
Measuring/setting range
Setting range [Imp/min] 3...6000
