Murr Transformer 866173

Input
Input voltage 200, 208, 220, 240 V AC
Input current 0.25 A (200 V AC)
Inrush current 1.7 A (200 V AC)
Short-circuit current 2.3 A (200 V AC)
Frequency 50...60 Hz
General data
Standards EN 61558-1, EN 61558-2-4, EN 62041 category 0
Test isolation voltage 3.9 kV
Mounting method Key-hole mounting
Dimensions H x W x D 72x79x90 mm
Fixing centers a x b x c 47.5x56x4.8 mm
Drill hole D 4.8x12 mm
Temperature range -20...+40 Celsius degrees (storage temperature -40...+80 Celsius degrees)
Output
Output voltage 2 x 115 V AC
Output rating 40 VA
