Sensata-Crydom Relay PMP2490W

The Sensata-Crydom Relay is high quality! OUTPUT:
Load Current, General Use UL508 @ 40°C [ARMS]:90
Minimum Load Current [mArms]:150
Maximum 1 Cycle Surge Current (50/60Hz) [Apk]:1290/1350
Maximum On-State Voltage Drop @ Rated Current [Vrms]:1.2
Maximum 1/2 Cycle I2 t for Fusing (50/60Hz) [A2 sec]:8320/7593
Thermal Resistance Junction to Case (Rjc) [°C/W]:0.2
Maximum Power Dissipation @ Rated Current [W]:104
Recommended Heat Sink for Rated Current @ 40oC [°C/W]:0.36
Minimum Power Factor (at Maximum load):0.7
Phase Angle Control Range [%]:0 to 100
Burst Fire Distributive Control Time Base Period:0 to 20 Cycles
INPUT:Voltage Control:Valid Input Voltage [VDC] / Current [mA]:0-10, 0-5
Maximum Allowed Input Voltage [VDC] / Current [mA]:30
Maximum Reverse Voltage [VDC] /Current [mA]:-30
Pick up Voltage [VDC] / Current [mA]:0.4
Dropout Voltage [VDC] / Current [mA]:0.1
Nominal Input Impedance [Ohms]:28.8k
Maximum Initialization Time [msec]:5 Cycles
Response Time:1 Cycle
Current Control:Valid Input Voltage [VDC] / Current [mA]:4-20
Maximum Allowed Input Voltage [VDC] / Current [mA]:35
Maximum Reverse Voltage [VDC] /Current [mA]:-35
Pick up Voltage [VDC] / Current [mA]:4.3
Dropout Voltage [VDC] / Current [mA]:4
Nominal Input Impedance [Ohms]:230 @ 20 mA
Maximum Initialization Time [msec]: 5 Cycles
Response Time: 1 Cycle
